Deploying Apache Airflow on Azure Kubernetes Service

This post will describe how you can deploy Apache Airflow using the Kubernetes executor on Azure Kubernetes Service (AKS). It will also go into detail about registering a proper domain name for airflow running on HTTPS. To get the most out of this post basic knowledge of helm, kubectl and docker is advised as it the commands won’t be explained into detail here. In short, Docker is currently the most popular container platform and allows you to isolate and pack self-contained environments. Kubernetes (accessible via the command line tool kubectl) is a powerful and comprehensive platform for orchestrating docker containers. Helm is a layer on top of kubectl and is an application manager for Kubernetes, making it easy to share and install complex applications on Kubernetes.

Getting started

To get started and follow along:

1. Clone the Airflow docker image repository
2. Clone the Airflow helm chart

Make a copy of ./airflow-helm/airflow.yaml to ./airflow-helm/airflow-local.yaml. We’ll be modifying this file throughout this guide.

Kubernetes Executor on Azure Kubernetes Service (AKS)

The kubernetes executor for Airflow runs every single task in a separate pod. It does so by starting a new run of the task using the airflow run command in a new pod. The executor also makes sure the new pod will receive a connection to the database and the location of DAGs and logs.

AKS is a managed Kubernetes service running on the Microsoft Azure cloud. It is assumed the reader has already deployed such a cluster – this is in fact quite easy using the quick start guide. Note: this guide was written using AKS version 1.12.7.

The fernet key in Airflow is designed to communicate secret values from database to executor. If the executor does not have access to the fernet key it cannot decode connections. To make sure this is possible set the following value in airflow-local.yaml:

airflow:
  fernetKey:

Use bcb.github.io/airflow/fernet-key to generate a fernet key.

This setting will make sure the fernet key gets propagated to the executor pods. This is done by the Kubernetes Executor in Airflow automagically.

Deploying with Helm

In addition to the airflow-helm repository make sure your kubectl is configured to use the correct AKS cluster (if you have more than one). Assuming you have a Kubernetes cluster called aks-airflow you can use the azure CLI or kubectl.

az aks get-credentials --name aks-airflow --resource-group MyResourceGroup

or

kubectl config use-context aks-airflow

respectively. Note that the latter one only works if you’ve invoked the former command at least once.

Azure Postgres

To make full use of cloud features we’ll be connected to a managed Azure Postgres instance. If you don’t have one, the quick start guide is your friend. All state for Airflow is stored in the metastore. Choosing this managed database will also take care of backups, which is one less thing to worry about.

Now, the docker image used in the helm chart uses an entrypoint.sh which makes some nasty assumptions:

It creates the AIRFLOW<strong>CORE</strong>SQL_ALCHEMY_CONN value given the postgres host, port, user and password.
The issue is that it expects an unencrypted (no SSL) connection by default. Since this blog post uses an external postgres instance we must use SSL encryption.

The easiest solution to this problem is to modify the Dockerfile and completely remove the ENTRYPOINT and CMD line. This does involve creating your own image and pushing it to your container registry. The Azure Container Registry (ACR) would serve that purpose very well.

We can then proceed to create the user and database for Airflow using psql. The easiest way to do this is to login to the Azure Portal open a cloud shell and connect to the postgres database with your admin user. From here you can create the user, database and access rights for Airflow with

create database airflow;
create user airflow with encrypted password 'foo';
grant all privileges on database airflow to airflow;

You can then proceed to set the following value (assuming your postgres instance is called posgresdbforairflow) in airflow-local.yaml:

airflow:
  sqlalchemy_connection: postgresql+psycopg2://airflow@posgresdbforairflow:[email protected]:5432/airflow?sslmode=require

Note the sslmode=require at the end, which tells Airflow to use an encrypted connection to postgres.

Since we use a custom image we have to tell this to helm. Set the following values in airflow-local.yaml:

airflow:
  image:
    repository: youracrservice.azurecr.io/custom-docker-airflow
    tag: 1.10.2
    pullPolicy: IfNotPresent
    pullSecret: acr-auth

Note the acr-auth pull secret. You can either create this yourself or – better yet – let helm take care of it. To let helm create the secret for you, set the following values in airflow-local.yaml:

imageCredentials:
  registry: youracrservice.azurecr.io
  username: youracrservice
  password: password-for-azure-container-registry

The sqlalchemy connection string is also propagated to the executor pods. Like the fernet key, this is done by the Kubernetes Executor.

Persistent logs and dags with Azure Fileshare

Microsoft Azure provides a way to mount SMB fileshares to any Kubernetes pod. To enable persistent logging we’ll be configuring the helm chart to mount an Azure File Share (AFS). Out of scope is setting up logrotate, this is highly recommended since Airflow (especially the scheduler) generates a LOT of logs. In this guide, we’ll also be using an AFS for the location of the dags.

Set the following values to enable logging to a fileshare in airflow-local.yaml.

persistence:
  filestore:
    storageAccountName: yourazuresstorageaccountname
    storageAccountKey: yourazurestorageaccountkey
  logs:
    secretName: logssecret
    shareName: yourlogssharename
  dags:
    secretName: dagssecret
    shareName: yourdagssharename

The name of shareName must match an AFS that you’ve created before deploying the helm chart.

Now everything for persistent logging and persistent dags has been setup.

This concludes all work with helm and airflow is now ready to be deployed! Run the following command from the path where your airflow-local.yaml is located:

helm install --namespace "airflow" --name "airflow" -f airflow-local.yaml airflow/

The next step would be to exec -it into the webserver or scheduler pod and creating Airflow users. This is out of scope for this guide.
