EventStorming; Core concepts, glossary and legend
Recently on Twitter Chris Richardson asked if anyone has created a consistent and comprehensive glossary for EventStorming core concepts.
I replied saying that #EventStorming is fuzzy by design. There are standard core concepts, and depending on the context, we use different words for the post-its. Because with that fuzziness, you get more insights. I call it just enough structure to let transactional conversations flow and create a shared mindset and tons of new insight—a shared pool of understanding. However thinking back at past workshops, and from skimming the EventStorming book checking out the core concepts, Chris has a point, we lack an excellent consistent glossary of the core concept, also specific per type. This post describes my take on EventStorming core concepts written down in a consistent and comprehensive glossary. Just be sure to try and avoid jargon as much as possible, as it sets up the unnecessary insider-outsider distinction.
I have moved the content of this blog to the DDD-crew GitHub page, were it will be updated by the community.https://github.com/ddd-crew/eventstorming-glossary-cheat-sheet
(A lot of sources comes from the unfinished Leanpub book by Alberto Brandolini: https://leanpub.com/introducing_eventstorming)
Create a visible legend
Let me start by explaining a guiding heuristics that I always use, and it is to use a visible legend. Because words are ambiguous, you might change the naming of the concepts explained here. A good example is that ‘policy’ causes a lot of confusion in an insurance domain so that I might use ‘process’ instead. So each EventStorming can be different and thus we need to create a visible legend to add the notion and colour coding we are using for that workshop.
EventStorming Core Concepts
A Domain Event is the main concept of EventStorming. It is an event that is relevant for the domain experts and contextual for the domain that is being explored. A Domain Event is a verb at the past tense. The official EventStorming colour is orange.
Hotspots are used to visualise and capture hot conflicts. Conflicts caused by, and not exclusive to, inconsistencies (in language), frictions, questions, dissent, objections, issues or procrastinating going deep to explore for later. The official EventStorming colour is neon pink and we also slighly pivot a hotspot when we use it.
EventStorming is a powerfull tool when we have a story to tell, when we have a timeline. The paper roll on the wall represents time from left to right. We can have parallel streams from top to bottom on the paper roll.
Chaotic exploration can be used at the start of EventStorming. Each person writes Domain Events by themselves that they can think off. They will put these Domain Events in order they think they happen on the paper roll.
Enforce the Timeline
A phase happening after chaotic exploration, meaning we try to make the timeline consistent and remove duplicate stickies.
Big Picture EventStorming
The goal of Big Picture EventStorming is to assess the health of an existing line of business or explore the viability of a new startup business model. It helps the group create a shared state of mind of the vision of that domain of the company. We can use the output as input for Conway’s law alignment, organising business flow around teams and software with emergent bounded contexts. You can do these workshop with 10-30+ people on one paper roll.
Because a Hotspot can have a negative association we also give people the chance to add opportunities. We use green because of the accosiation it has with something positive. Start using Opportunities after we made a consistent timeline.
Actor or Agent is a group of people, a department, a team or a specific person involved around a (group of) Domain Event(s). The official colour to use is a small yellow post-it.
A system is a deployable IT System used as a solution for a problem in the domain. When we finished making the timeline consistent we can start mapping systems around Domain Events. There can also be duplicates and it can be anything from using Excel to some microservice. The official colour is a wide pink post-it.
We can add value like we would do in a value stream map once we made the timeline consistent. We do this to make explicit where the value is in our domain. We use the red and green small stickies to show positive and negative value.
With Pivotal Events, we start looking for the few most significant events in the flow. For an e-commerce website, they might look like “Article Added to Catalogue”, “Order Placed”, “Order Shipped”, “Payment Received” and “Order Delivered”. These are often the events with the highest number of people interested.
Separating the whole flow into horizontal swimlanes, assigned to given actors or departments, is another tempting option since it improves readability. This seems the most obvious choice for people with a background in process modelling
Emerging Bounded Context
From a Big Picture EventStorming we can picture Emerging Bounded Context. They are the first indicators of were to start deep-diving towards designing bounded context around business problems.
Process modelling EventStorming
The goal of process modelling EventStorming is to assess the health of a current process in the company. It helps the group create a shared state of mind of the current status quo of the process, finding bottlenecks and find parts of the system to decouple the existing software.
In essence, a policy is a reaction that says “whenever X happens, we do Y”. Eventually ending up with in the flow between a Domain Event and a Command/action. We use a big lilac post-it for these. A policy can be an automated process or manual. A policy can also be named a reactor, eventual business constraint or rule or a lie detector because there is always more to policies than you first think.
Represents decisions, actions or intent. They can be initiated by an actor or from an automated process. During process EventStorming usually, the word Action first better with stakeholders than command. We officially use a blue coloured post-it for it.
To make decisions an actor might need information, we capture these in a Query Model. For process EventStorming information might be more recognised by stakeholders. We officially use a green post-it to represent a query model.
Enforce colour coding
Enforcing the colour coding is playing EventStorming by the rules. Often used after or during enforcing the timeline it creates a different dynamic. Below you see the colour coding and how they are to be used in the flow of the timeline.
Software Design EventStorming
The outcome of a design level EventStorming is to design clean and maintainable Event-Driven software, to support rapidly evolving businesses. Together with business stakeholders, we design a shared language and represent that in a shared model that brings value in solving a problem within a bounded context.
Aggregate/Consistent Business Rule
An aggregate is a Domain-Driven Design pattern that represents cluster of domain objects to make invalid state unrepresentable. We use the big yellow post-it to represent it. Because we want to avoid using the DDD jargon with our stakeholder, we can also use consistent business rule or constraint instead.
I hope this glossary helps, and if you have any feedback let me know in the comments or message me on twitter.
You can also find this post of my personal blog page.
